4-36
Chapter 4: Software support
Chapter 4
Remote Desktop Control Notification
Thisfunctionallowsyoutosendthecontrolauthorizationtoasmartdeviceanddirectlystart
usingRemoteDesktopinyourdevice.
TouseRemoteDesktopControlNotication:
1. ClickSelectDevice.
2. Selectadevicefromthedroplist.
3. ClickSendtosendtheRemoteDesktopcontrolauthorizationtotheselecteddevice.
ThisfunctionrequiresthePushNoticefeaturetobeinstalled.YoucangetthePUSHNotice
installerfromthebundledsupportDVDordownloadthelatestinstallerfrom
www.asus.com.
