ASUS RAMPAGE V EXTREME
4-13
Chapter 4
Turbo App
TurboAppallowsyoucustomizethesystemperformance,networkpriority,andaudiosetting
ofanapplication.
WhenanapplicationisontheTurboAppList,youcansettheCPUfrequency,assigna
networkpriority,anddenetheaudiosettingoftheselectedapplication.
Click to apply
the changes
Click to scroll up/down
Click to undo
the changes
Click to assign a specific application(.exe)
into Turbo App list
Click to refresh the list of running applications
Applications list pane
Displaysalltherunningapplicationsonyoursystem.
Turbo App List pane
DisplaystheapplicationsaddedtotheTurboAppList.
* Only applications on the Turbo App List can be configured.
Performance pane
AllowsyoutoassignaCPUperformanceproletoaselectedapplication.
Audio pane
Allowsyoutomanuallyassignapresetaudiocongurationtoaselected
application.
LAN pane
Allowsyouassignanetworkprioritytoaselectedapplication.
