Chapter 8 Optional Cards
8-11
Wiring Diagram
Please use a shielded cable to prevent interference. Do not run control wires parallel to any high voltage
AC power line (200 V and above).
Recommended wire size 0.21 to 0.81mm
2
(AWG24 to AWG18).
Cable length: Less than 100m
R/L1
S/L2
T/L3
NFB
R
S
T
+1
+2/B1
B2
U/T1
V/T2
W/T3
M
3~
-
U
W
V
EMC-PG01U
AO
AO
BO
BO
ZO
ZO
VP
DCM
A1
A1
B1
B1
Z1
Z1
PG
U1
U1
V1
V1
W1
W1
A2
A2
B2
B2
EH-PLC
Y0
Y0
Y1
Y1
Y0
Y0
Y1
Y1
SG
AO
AO
BO
BO
Line driver
Jumper
No-Fuse Breaker
Braking resistor (optional)
Motor
Encoder
Phase difference90
o
Phase difference90
o
