Chapter 12 Description of Parameter SettingsCH2000 Series

12-60

Release Brake Check

Factory Setting:

0.000

Settings 0.000~65.000 sec

 This parameter needs to work with function MI =55 Brake Release. This parameter is to

measure the time interval difference between brake release delay time and brake release

time.



FWD Brake Current

Factory setting: 0

Settings 0~150%



FWD Brake Frequency

Factory setting：0.00

Settings 0.00~655.35Hz

 Pr02-32, Pr02-33, Pr02-34, Pr02-57 and Pr02-58 can be applied on setting up cranes. (Choose

crane action #42 to set up multi-functional output Pr02-13, Pr02-14, Pr02-16, and Pr02-17)

 When output current of a drive is higher than the setting of Pr02-33 Pivot Point of the Current

(>=02-33) and when output frequency is higher than the setting of Pr02-34 Pivot Point of the

Frequency (>= 02-34), choose #42 to set up Multi-functional output Pr02-13, Pr02-14, Pr02-16 and

Pr002-17 after the delay time set at Pr02-32.

 When the Pivot Point of the Current 's setting 02-57≠0 and when the output current of the drive is

lower than the setting of Pr02-57 (<02-57), or when the output frequency is lower than the setting of

Pr02-58 (<02-58), the disable the setting #42 of the multi-functional output Pr02-13, Pr02-14,

Pr02-16, Pr02-17

 When Pr02-57 = 0, the output current is lower than setting of Pr02-33 Pivot Point of the current

(<02-33) or when output frequency is lower than the setting of Pr02-58(<02-58), disable the setting

of #42 of the multi-functional output Pr02-13, Pr02-14, Pr02-16, Pr02-17.

02 - 59

REV Release Current

Factory setting: 0

Settings 0~100%

02 - 60

REV Brake Current

Factory setting: 0

Settings 0~100%
