Chapter 15 CANopen Overview C2000 Series
15-32
Display
Fault code Description
CANopen
fault code
CANopen
fault
register
(bit 0~7)
Thermal relay 2
Fault
cP10
Keypad time out
Fault
003BH Keypad transmission timeout. 7500H 4
Thermal relay 2
Fault
bF
Braking fault
Fault
003CH Brake resistor fault 7110H 4
Thermal relay 2
Fault
ydc
Y-delta connect
Fault
003DH Motor Y-Δ switch error 3330H 2
Thermal relay 2
Fault
dEb
Dec. Energy back
Fault
003EH Energy regeneration when decelerating FF27H 2
Thermal relay 2
Fault
oSL
Over slip Error
Fault
003FH
Over slip error. Slip exceeds Pr.05.26
limit and slip duration exceeds Pr.05.27
setting.
FF28H 7
Thermal relay 2
Fault
PGF5
PG HW Error
Fault
0041H PG Card Error FF29H 5
Thermal relay 2
Fault
ovU
Over volt. Unknow
Fault
Thermal relay 2
Fault
ocU
Unknow Over Apm
Fault
0042H over current caused by unknown reason 2310H 1
Thermal relay 2
Fault
ovU
Unknow Over volt.
Fault
0043H over voltage caused by unknown reason 3210H 2
Thermal relay 2
Fault
S1
S1-Emergy stop
Fault
0049H external safety emergency stop FF2AH 5
Thermal relay 2
Fault
OPHL
U phase lacked
Fault
0052H U phase output phase loss 2331H 2
Thermal relay 2
Fault
OPHL
U phase lacked
Fault
0053H
V phase output phase loss
2332H 2
