SiBE27-702 Field Settings
Test Operation 105
Possible system
settings
The table below contains the possible system settings, which are displayed on the remote
controller if the TEST button is pushed twice shortly.
Changing the
mode settings
To enter the monitoring level and to change the maintenance mode settings, proceed as
follows:
Size
Software
Type
Settings Display Settings Display
35 35
5
FCQ-B FJ
45 45 FHQ HJ
60 63 FAQ AJ
71 71 FFQ GJ
100 100 FBQ JJ
125 125 FUQ 3J
140 140 FCQ-D FJ
200 200 FDQ UJ
250 250 – –
Step Action
1 Hold down the INSPECTION/TEST button for at least 4 s to enter the field setting mode.
2 Hold down the INSPECTION/TEST button for at least 4 s to enter the maintenance
mode.
3 Press the TEMPERATURE CONTROL buttons as many times as needed to select the
mode No. you want.
4 Press the TIMER SELECTION button as many times as needed to select the unit No.
you want.
5 Carry out the settings for modes 44 and 45. See “Maintenance Mode Settings” further
in this section.
6 Press the CONFIRMATION button to confirm the settings of modes 44 and 45.
7 Press the INSPECTION/TEST button to return to the normal operating mode.
