Daikin RZQS100B7V3B [218/344] J1 malfunction of pressure sensor
![Daikin RZQS100B7V3B [218/344] J1 malfunction of pressure sensor](/views2/1769683/page218/bgda.png)
SiBE27-702 Troubleshooting by Remote Controller Display / LED Display
Troubleshooting 205
5.27 “J1” Malfunction of Pressure Sensor
Remote
Controller
Display
J1
Applicable
Models
RZQ100~140C7V1B
RZQS125·140C7V1B
Method of
Malfunction
Detection
The malfunction is detected by the pressure measured with pressure sensor (S1NPH)
Malfunction
Decision
Conditions
When the detect pressure becomes following;
•
Detected pressure
≤
-0.05MPa continues 185 sec.
•
Detected pressure
≥
4.4MPa continues 185 sec.
Supposed
Causes
Faulty pressure sensor
Faulty outdoor unit PC board
Incorrect connection of connector
