Troubleshooting by Remote Controller Display / LED Display SiBE27-702
220 Troubleshooting
Troubleshooting
Is the fan
motor connector
connected?
Is the
transmission
wiring between the
control and inverter
PC board
disconnected?
Is the
microcomputer
normal monitor (green) on
inverter PC board
blinking?
Is the
microcomputer
normal LED on control
PC board
blinking?
Is “E7”
displayed on the remote
controller? (Is “LC” not
displayed?)
Are
connectors
connecting the
control and inverter PC
board connected
securely?
Disconnect the fan motor
connector, and turn on again.
Caution
Be sure to turn off power switch before connect or disconnect connector,
or parts damage may be occurred.
Connect the transmission
wiring, and turn on again.
Connect the connector, and
turn on again.
Fix the disconnection, and
turn on again.
Replace the fan motor.
Inverter transmission
malfunctioned due to the
malfunction of fan motor.
Check for faulty connector
connection in the transmission
wiring and for clamps with
high tension line.
NO
YES
YES
NO
NO
NO
YES
YES
YES
NO
NO
YES
RZQ71B9, RZQS71·100B7 (1φ),
RZQ100~140B8 (3φ):
Replace the outdoor control PC
board (A1P).
RZQ100~140C7,
RZQS125·140C7 (1φ):
Replace the outdoor PC board
(A1P).
RZQ71B9, RZQS71·100B7 (1φ),
RZQ100~140B8 (3φ):
Replace the outdoor inverter PC
board (A2P).
RZQ100~140C7,
RZQS125·140C7 (1φ):
Replace the outdoor PC board
(A2P).
