SiBE27-702 General Functionality
Functional Description 41
1.3 Outdoor Unit Identification Function
Purpose The purpose of the outdoor unit identification function is to enable the indoor unit to
automatically determine which operating mode has to be set in function of the type of connected
outdoor unit (C/O or H/P).
Operating modes The possible operating modes are:
Used input The outdoor unit identification function uses the following inputs:
TC: Transmission circuit
RC: Receiving circuit
Outdoor unit Operating modes
H/P Fan
Cooling
Dry keep
Heating
C/O Fan
Cooling
Dry keep
Input
Connection on
indoor PCB
Connection on
outdoor PCB
Indoor PC board TC & RC —
Outdoor PC board — TC & RC
