SiBE27-702 Specifications
Specifications 11
Notes:
1. Nominal cooling capacities are based on:
Indoor temperature: 27.0°C DB/19.0°C WB
Outdoor temperature: 35.0°C DB
Equivalent refrigerant piping: 7.5 m
Level difference: 0 m
2. Nominal heating capacities are based on:
Indoor temperature: 20°C DB
Outdoor temperature: 7.0°C DB/6.0° C WB
Equivalent refrigerant piping: 7.5 m
Level difference: 0 m
Piping
connections
Liquid quantity 1
Liquid type Flare connection
Liquid diameter (OD) 9.52 mm
Gas quantity 1
Gas type Flare connection
Gas diameter (OD) 15.9 mm
Drain quantity 3
Drain type Hole
Drain diameter (OD) 26.0 mm
Piping length min. 5 m
Piping length max. 50 m 75 m
Piping length equivalent 70 m 95 m
Piping length chargeless 30 m
Additional refrigerant charge
See installation manual
4PW21412-1
See installation manual 4PW34874-1
Installation height difference max. 30.0 m
Max. intern unit level difference 0.50 m
Heat insulation Both liquid and gas pipes
Defrost method Pressure equalising
Defrost control Sensor for outdoor heat exchanger temperature
Capacity control method Inverter controlled
Safety devices
High pressure switch
Fan motor thermal protector
Fuse
Standard
accessories
Item Tie-wraps
Quantity 2
Standard
accessories
Item Installation manual
Quantity 1
