Frequency Regulating Functions SiBE27-702
80 Functional Description
4.8 Inverter Current Protection Control
4.8.1 Control by inverter fin temperature
Restricts compressor operation upper limit frequency to prevent compressor from tripping due
to inverter fin temperature.
4.8.2 Inverter current protection control
Restricts compressor operation frequency to prevent compressor from tripping due to inverter
overcurrent.
1 phase 3 phase
A84 80
B81 77
Normal operation
Compressor frequency
+1 step/2 min
Inverter upper limit frequency
= Maximum frequency
Compressor frequency
–1 step/16 sec
Fin temperature ≤ B˚C
lasts for 2 minutes
Inverter fin temperature ≥ A˚C
1 phase 3 phase
RZQ71B9,
RZQS71
RZQS100B7V3B
RZQ100~140C7,
RZQS125·140C7V1B
RZQ100~140B8W1B
PA 11.7 A 13.7 A 20 A 11.0 A
QA 12.9 A 13.7 A 20 A 13.0 A
Normal operation
Compressor frequency
–1 step/6 sec
Compressor frequency
+1 step/2 min
Inverter current
>Stepping down current
Inverter upper limit frequency
= Maximum frequency
The condition of Inverter current<Stepping down
current continues for 2 minutes
Stepping-down
current QA
Stepping-down
current PA
&
Outdoor heat exchanger temperature
(liquid)≥Indoor heat exchanger
temperature
Outdoor heat exchanger temperature
(liquid)≥25˚C
OR
Outdoor heat exchanger temperature
(liquid)<Indoor heat exchanger
temperature
Outdoor heat exchanger temperature
(liquid)<25˚C
