SiBE27-702 Model Name and Power Supply
General Information 7
3. Model Name and Power Supply
Indoor Unit Outdoor Unit Power Supply
FCQ35C7VEB
RZQ71B9V3B
RZQS71B7V3B
1 phase 230V 50Hz
1 phase 230V 50Hz
FCQ71C7VEB
FCQH71C7VEB
FFQ35BV1B
FBQ35B7V1
FHQ35BUV1B
FHQ71BUV1B
FUQ71BUV1B
FAQ71BUV1B
FBQ71B7V3B
RZQ100C7V1B
RZQS100B7V3B
RZQ100B8W1B
1 phase 230V 50Hz
1 phase 230V 50Hz
3 phase 400V 50Hz
FCQ35C7VEB
FCQ50C7VEB
FCQ100C7V3B
FCQH100C7V3B
FFQ35BV1B
FFQ50BV1B
FBQ35B7V1
FBQ50B7V1
FBQ100B7V3B
FHQ35BUV1B
FHQ50BUV1B
FHQ100BUV1B
FUQ100BUV1B
FAQ100BUV1B
FCQ35C7VEB
RZQ125C7V1B
RZQS125C7V1B
RZQ125B8W1B
1 phase 230V 50Hz
1 phase 230V 50Hz
3 phase 400V 50Hz
FCQ50C7VEB
FCQ60C7VEB
FCQ125C7VEB
FCQH125C7VEB
FFQ35BV1B
FFQ50BV1B
FFQ60BV1B
FBQ35B7V1
FBQ50B7V1
FBQ60B7V1
FBQ125B7V3B
FDQ125B7V3B
FHQ35BUV1B
FHQ50BUV1B
FHQ60BUV1B
FHQ125BUV1B
FUQ125BUV1B
FCQ35C7V3B
RZQ140C7V1B
RZQS140C7V1B
RZQ140B8W1B
1 phase 230V 50Hz
1 phase 230V 50Hz
3 phase 400V 50Hz
FCQ50C7V3B
FCQ71C7V3B
FCQ140C7V3B
FCQH71C7V3B
FCQH140C7V3B
FFQ35BV1B
FFQ50BV1B
FBQ35B7V1
FBQ50B7V1
FBQ71B7V3B
FHQ35BUV1B
FHQ50BUV1B
FHQ71BUV3B
FUQ71BUV1B
FAQ71BUV1B
