Troubleshooting by Remote Controller Display / LED Display SiBE27-702
182 Troubleshooting
5.15 “E1” Failure of Outdoor Unit PC Board
Remote
Controller
Display
E1
Method of
Malfunction
Detection
Microcomputer checks whether E
2
PROM is normal.
Malfunction
Decision
Conditions
E
2
PROM:
When E
2
PROM malfunctions when turning the power supply on
Supposed
Causes
Faulty outdoor unit PC board
Troubleshooting
Turn the power
supply off once and
then back on
NO
NO
YES
YES
Is normal reset possible?
Tur n
the power
supply off and
disconnect the fan motor
connector from the PC board,
then turn the power supply
on again. Is "E1"
displayed?
Caution
Be sure to turn off power switch before connect or disconnect connector,
or parts damage may be occurred.
Problem could be caused by
external factor (noise, etc.)
other than malfunction.
Fan motor check
RZQ71B9, RZQS71·100B7
(1φ), RZQ100~140B8 (3φ):
Replace the outdoor
control PC board (A1P).
RZQ100~140C7,
RZQS125·140C7 (1φ):
Replace the outdoor PC
board.
