Troubleshooting by Remote Controller Display / LED Display SiBE27-702
166 Troubleshooting
5.5 Overview of the Indoor Safety Devices
Thermal protector Thermal fuse fan motor
Abnormal Reset (automatic)
FFQ35~60 >130°C +/-5°C <83°C +/-20°C N.A.
FCQ35~71 >130°C +/-5°C <83°C +/-20°C N.A.
FCQ100~140 >140°C +/-5°C <45°C +/-15°C N.A.
FBQ35~125 N.A. N.A. >152°C
FDQ125 N.A. N.A. >160°C
FHQ35~125 >130°C +/-5°C <83°C +/-20°C N.A.
FUQ71~125 >130°C +/-5°C <83°C +/-20°C N.A.
FAQ71/100 >130°C +/-5°C <83°C +/-20°C N.A.
