Troubleshooting by Remote Controller Display / LED Display SiBE27-702
200 Troubleshooting
Troubleshooting
Is the
discharge pipe
thermistor characteristic
normal?
(*2.)
Is the
discharge pipe
thermistor correctly
connected to PCB
(A1P)?
Is the
discharge pipe
temperature high?
(See *1.)
Is the
discharge pipe
thermistor attached to the
discharge pipe?
Caution
Be sure to turn off power switch before connect or disconnect connector,
or parts damage may be occurred.
Abnormality in refrigerant system
such as gas shortage, faulty
compressor, etc. Conduct
inspection
Connect correctly, and operate the
unit again.
Attach the thermistor, and operate
the unit again.
Replace the discharge pipe
thermistor.
Model name
RZQ71B9V3B,
RZQS71·100B7V3B (1φ)
RZQ100 ~ 140C7V1B,
RZQS125·140C7V1B (1φ),
RZQ100 ~ 140B8W1B (3φ)
Temperature
110˚C
115˚C
NO
YES
NO
YES
YES
NO
NO
YES
*1 Temperature varies depending on model type.
*2 Refer to “ Check 5 (P242)” for "Thermistor temperature – resistance conversion table”
RZQ71B9, RZQS71·100B7
(1φ), RZQ100~140B8 (3φ):
Replace the outdoor
control PC board (A1P).
RZQ100~140C7,
RZQS125·140C7 (1φ):
Replace the outdoor PC
board (A1P).
