Troubleshooting by Remote Controller Display / LED Display SiBE27-702
164 Troubleshooting
5.3 System Malfunctions
System
Malfunction
Remote
Controller
Display
Location of Malfunction Contents of Malfunction Details of
Malfunction
(Reference
Page)
Other
than PC
Board
PC Board
Outdoor
Unit
Indoor
Unit
Remote
Controller
U4
or
UF
{ { — Transmission error (between
indoor and outdoor unit)
229
UF
{ { — Malfunction of transmission
(between indoor and outdoor unit)
or
Piping and wiring mismatch
or
Gas shortage
232
U5
— {{Transmission error (between
indoor and remote controller)
233
U8
— {{Transmission error between
“main” remote controller and
“sub” remote controller
234
UA
— { — Excessive indoor units connected
to this system.
235
UC
—— { Centralized address setting error 237
