SiBE27-702 Troubleshooting by Remote Controller Display / LED Display
Troubleshooting 235
5.45 “UA” Malfunctioning Field Setting Switch
Remote
Controller
Display
UA
Applicable
Models
All models of indoor units
Error generation The error is generated when incorrect field settings have been set for pair/twin/triple/double
twin.
Supposed
Causes
The possible causes are:
Malfunctioning indoor or outdoor unit PC board
Malfunctioning power supply PC board
Indoor-outdoor, indoor-indoor unit transmission wiring
Malfunctioning remote controller wiring.
