SiBE27-702 Method of Operating Remote Controller
Remote Controller 33
3.3 Operation of the Remote Controller’s Inspection / Test
Operation Button
Inspection/test
operation
Indoor unit system code
Indoor unit type code
Display
2AA
Outdoor model code
Unit
Malfunction code
Inspection
Normal display (No display)
0
L 0
Malfunction code blinks when a malfunction occurs.
Unit
Malfunction code
Inspection
Inspection mode
Push the button.
Inspection/test
operation
Push the button.
Inspection/test
operation
Push the button.
Inspection/test
operation
Push the button.
Inspection/test
operation
Push the button.
0
L 0
Indoor unit model code display
0 7 1
F J J
Outdoor unit model code display
– – –
A A 1
Test operation
Test operation mode
Capacity code
Indoor unit system code
Indoor unit type code
Progression code
0 7 1...
F...
J...
J...
(V2775)
Display
F
System classification
Standard indoor unit
Model
RZQ-C
Type
Double flow
Multi flow
Built-In
High static pressure
Ceiling suspended
Ceiling suspended cassette
Wall mounted
Display
C
F
J
P
H
5
A
Model
FCQ
FFQ
FBQ
FDQ
FHQ
FUQ
FAQ
