Troubleshooting by Remote Controller Display / LED Display SiBE27-702
178 Troubleshooting
5.12 “C4”, “C9” Thermistor Abnormality
Remote
Controller
Display
The table below describes the two thermistor abnormalities.
LED indications The table below shows the LED indications.
Error generation The error is generated when during compressor operation:
Thermistor input > 4.96 V, or
Thermistor output < 0.04 V.
Supposed
Causes
The possible causes are:
Malfunctioning connector connection
Malfunctioning thermistor
Malfunctioning PC board
Broken or disconnected wire.
Checking
thermistors
Refer to P240.
Error Description
C4
Malfunctioning heat exchanger thermistor system.
C9
Malfunctioning suction air thermistor system.
Operation HAP (green) HBP (green)
Normal
55
Malfunctioning
55
