Specifications SiBE27-702
16 Specifications
1.2.2 Electrical Specifications
The table below contains the electrical specifications.
1.2.3 Electrical Data
Specification RZQS71B7V3B RZQS100B7V3B RZQS125C7V1B RZQSC7V1B
Power supply
Name V3B V1B
Phase 1~
Frequency 50 Hz
Voltage 230 V
Current
Zmax. List Complies to EN61000-3-11
Recommended fuses 20 A 32 A
Voltage range
Mininum 207 V
Maximum 253 V
Wire connections
For power supply - remark See installation manual 4PW32097-1 See installation manual 4PW34874-1
For connection with indoor - remark See installation manual 4PW32097-1 See installation manual 4PW34874-1
Power supply intake Outdoor unit only
Notes See separate drawing for electrical data.
See separate drawing for
electrical data.
Power supply intake for
FDQ is outdoor and
indoor unit.
See separate drawing for
electrical data.
Unit combination Power supply Compressor OFM IFM
Indoor unit Outdoor unit Hz-Volts Voltage range MCA TOCA MFA MSC RLA kW FLA kW FLA
FCQH71C7VEB RZQS71B7V3B 50-230
Max.50Hz253V
Min.50Hz207V
17.0 17.0 20 16.2 16.2 0.07 0.3 0.120 0.5
FCQ71C7VEB RZQS71B7V3B 50-230 17.0 17.0 20 16.2 16.2 0.07 0.3 0.056 0.5
FCQ35C7VEB×2 RZQS71B7V3B 50-230 17.1 17.1 20 16.2 16.2 0.07 0.3 0.056×2 0.3×2
FFQ35BV1B×2 RZQS71B7V3B 50-230 17.7 17.7 20 16.2 16.2 0.07 0.3 0.055×2 0.6×2
FBQ71B7V3B RZQS71B7V3B 50-230 17.4 17.4 20 16.2 16.2 0.07 0.3 0.125 0.9
FBQ35B7V1×2 RZQS71B7V3B 50-230 17.5 17.5 20 16.2 16.2 0.07 0.3 0.065×2 0.5×2
FHQ71BUV1B RZQS71B7V3B 50-230 17.1 17.1 20 16.2 16.2 0.07 0.3 0.062 0.6
FHQ35BUV1B×2 RZQS71B7V3B 50-230 17.7 17.7 20 16.2 16.2 0.07 0.3 0.062×2 0.6×2
FAQ71BUV1B RZQS71B7V3B 50-230 16.8 16.8 20 16.2 16.2 0.07 0.3 0.043 0.3
FCQH100C7VEB RZQS100B7V3B 50-230
Max.50Hz253V
Min.50Hz207V
19.4 19.4 20 17.7 17.7 0.07 0.3 0.120 1.4
FCQ100C7VEB RZQS100B7V3B 50-230 18.7 18.7 20 17.7 17.7 0.07 0.3 0.120 0.7
FCQ50C7VEB×2 RZQS100B7V3B 50-230 18.6 18.6 20 17.7 17.7 0.07 0.3 0.056×2 0.3×2
FCQ35C7VEB×3 RZQS100B7V3B 50-230 18.9 18.9 20 17.7 17.7 0.07 0.3 0.056×2 0.3×3
FFQ50BV1B×2 RZQS100B7V3B 50-230 19.4 19.4 20 17.7 17.7 0.07 0.3 0.055×2 0.7×2
FFQ35BV1B×3 RZQS100B7V3B 50-230 19.8 19.8 20 17.7 17.7 0.07 0.3 0.055×3 0.6×3
FBQ100B7V3B RZQS100B7V3B 50-230 19.0 19.0 20 17.7 17.7 0.07 0.3 0.135 1.0
FBQ50B7V1×2 RZQS100B7V3B 50-230 19.4 19.4 20 17.7 17.7 0.07 0.3 0.085×2 0.7×2
FBQ35B7V1×3 RZQS100B7V3B 50-230 19.5 19.5 20 17.7 17.7 0.07 0.3 0.065×3 0.5×3
FHQ100BUV1B RZQS100B7V3B 50-230 18.7 18.7 20 17.7 17.7 0.07 0.3 0.130 0.7
FHQ50BUV1B×2 RZQS100B7V3B 50-230 19.2 19.2 20 17.7 17.7 0.07 0.3 0.062×2 0.6×2
FHQ35BUV1B×3 RZQS100B7V3B 50-230 19.8 19.8 20 17.7 17.7 0.07 0.3 0.062×3 0.6×3
FAQ100BUV1B RZQS100B7V3B 50-230 18.4 18.4 20 17.7 17.7 0.07 0.3 0.049 0.4
FCQH125C7VEB RZQS125C7V1B
50-220
50-230
50-240
Max.50Hz264V
Min.50Hz198V
25.4 25.4 32 23.4 23.4
0.07+0.07
0.3+0.3 0.120 1.4
FCQ125C7VEB RZQS125C7V1B 25.0 25.0 32 23.4 23.4
0.07+0.07
0.3+0.3 0.120 1.0
FCQ60C7VEB×2 RZQS125C7V1B 24.8 24.8 32 23.4 23.4
0.07+0.07
0.3+0.3 0.056×2 0.4×2
FCQ50C7VEB×3 RZQS125C7V1B 24.9 24.9 32 23.4 23.4
0.07+0.07
0.3+0.3 0.056×3 0.3×3
FCQ35C7VEB×4 RZQS125C7V1B 25.2 25.2 32 23.4 23.4
0.07+0.07
0.3+0.3 0.056×4 0.3×4
FFQ60BV1B×2 RZQS125C7V1B 25.4 25.4 32 23.4 23.4
0.07+0.07
0.3+0.3 0.055×2 0.7×2
FFQ50BV1B×3 RZQS125C7V1B 26.1 26.1 32 23.4 23.4
0.07+0.07
0.3+0.3 0.055×3 0.7×3
FFQ35BV1B×4 RZQS125C7V1B 26.4 26.4 32 23.4 23.4
0.07+0.07
0.3+0.3 0.055×4 0.6×4
FBQ125B7V3B RZQS125C7V1B 25.4 25.4 32 23.4 23.4
0.07+0.07
0.3+0.3 0.225 1.4
FBQ60B7V1×2 RZQS125C7V1B 25.8 25.8 32 23.4 23.4
0.07+0.07
0.3+0.3 0.125×2 0.9×2
FBQ50B7V1×3 RZQS125C7V1B 26.1 26.1 32 23.4 23.4
0.07+0.07
0.3+0.3 0.085×3 0.7×3
FBQ35B7V1×4 RZQS125C7V1B 26.0 26.0 32 23.4 23.4
0.07+0.07
0.3+0.3 0.065×4 0.5×4
FHQ125BUV1B RZQS125C7V1B 24.7 24.7 32 23.4 23.4
0.07+0.07
0.3+0.3 0.130 0.7
FHQ60BUV1B×2 RZQS125C7V1B 25.2 25.2 32 23.4 23.4
0.07+0.07
0.3+0.3 0.062×2 0.6×2
FHQ50BUV1B×3 RZQS125C7V1B 25.8 25.8 32 23.4 23.4
0.07+0.07
0.3+0.3 0.062×3 0.6×3
FHQ35BUV1B×4 RZQS125C7V1B 26.4 26.4 32 23.4 23.4
0.07+0.07
0.3+0.3 0.062×4 0.6×4
FDQ125B7V3B RZQS125C7V1B 28.2 28.2 32 23.4 23.4
0.07+0.07
0.3+0.3 0.500 4.2
