Troubleshooting by Remote Controller Display / LED Display SiBE27-702
168 Troubleshooting
5.7 “A3” Malfunction of Drain Water Level System
Remote
Controller
Display
A3
LED indications The table below shows the LED indications.
Error generation The error is generated when the water level reaches its upper limit and when the float switch
turns OFF.
Supposed
Causes
The possible causes are:
Malfunctioning drain pump
Improper drain piping work
Drain piping clogging
Malfunctioning float switch
Malfunctioning indoor unit PC board
Malfunctioning short-circuit connector X15A on PC board.
Operation HAP (green) HBP (green)
Normal
55
Malfunctioning
55
