Field Settings SiBE27-702
114 Test Operation
d. “List of contents of retry and malfunction”
Take the following steps to check contents of retry and malfunction.
8
: ON
1
: OFF
9
: BLINK
Malfunction
code
Contents of retry or malfunction
123
HAP H1P H2P H3P H4P H5P H6P H7P HAP H1P H2P H3P H4P H5P H6P H7P HAP H1P H2P H3P H4P H5P H6P H7P
C4 Indoor heat exchanger thermistor
998777979987797799887777
E1 Faulty outdoor PC board
997877999987777999887777
E3 Abnormal high pressure
9987779999887777
E4 Abnormal low pressure
9987797799887777
E5 Compressor motor lock
9987797999887777
E7
Abnormal outdoor
fan motor
DC motor 1 lock
9987799999887779
DC motor 2 lock
99887797
Abnormal inverter transmission
99887799
E9
Abnormal electronic
expansion valve
Disconnected electronic expansion valve connector
9987977999887779
Malfunction due to wet conditions
99887797
F3
Abnormal discharge
pipe temperature
Abnormal discharge pipe temperature
997879799987779999887779
Disconnected discharge pipe thermistor
99887797
H3 Abnormal high pressure switch
997879779987779999887777
H9 Abnormal outdoor air thermistor
9987977999887777
J1 Abnormal pressure sensor
997879979987777999887777
J3 Abnormal discharge pipe thermistor
9987779999887777
J5 Abnormal suction pipe thermistor
9987797999887777
J6 Abnormal heat exchanger distributor pipe thermistor
9987799799887777
J7 Abnormal intermediate heat exchanger thermistor
9987799999887777
J8 Abnormal liquid pipe thermistor
9987977799887777
L1 PC board failure
997879999987777999887777
L4 Elevated radiation fin temperature
9987797799887777
L5 Compressor instantaneous overcurrent
9987797999887777
L8 Compressor overload
9987977799887777
L9 Compressor lock
9987977999887777
LC
Abnormal transmission (between the control and the inverter)
9987997799887777
P1 Unbalanced power supply voltage
997897779987777999887777
P4 Abnormal radiation fin thermistor
9987797799887777
PJ Faulty capacity setting
9987997999887777
U0
Abnormal gas
shortage
Gas shortage warning
997897799987777799887779
Abnormal gas shortage
99887797
U2
Abnormal power
supply voltage
Inverter undervoltage and overvoltage
9987779799887779
SP-PAM overvoltage
99887797
U4
Abnormal transmission (between indoor and outdoor units)
9987797799887777
UA Faulty field setting switch
9987979799887777
UF Improper piping and improper communication wiring
999999887777
To enter "Monitor mode," push the MODE (BS1)
button when in "Setting mode 1."
Push the SET (BS2) button to set the LED
display to retry or malfunction item.
When the RETURN (BS3) button is pushed, the
LED display for RETURN 1 turns ON.
<Selection of retry or malfunction item>
When SET (BS2) button is pushed, the LED
display for RETURN 2 turns ON.
<Display of RETURN 2>
When SET (BS2) button is pushed, the LED
display for RETURN 3 turns ON.
Push the RETURN (BS3) button to return the
system to the initial state of "Monitor mode."
∗ Pushing the MODE (BS1) button will bring the
system to the "Setting mode 1."
<Display of RETURN 3>
<Display of RETURN 1>
