Troubleshooting by Remote Controller Display / LED Display SiBE27-702
238 Troubleshooting
Outdoor Unit: Checking the Installation Condition
Checking To check the installation condition, proceed as follows:
Check No.1
NO
NO
NO
YES
YES
Check the spaces for all air
passage around the suction
and discharge areas.
Check the outdoor ambient
temperature R1T.
This temperature must be
lower than 43˚C.
Change the
installation location.
YES
Does the
discharged air from
other outdoor units cause an
increase of the suction
temperature?
Is the
minimum space
rescpected?
Is the
heat exchanger
clean?
YES
Is there
enough
air flow?
Clean the heat
exchanger.
Change the
installation location
or direction.
Change the
installation location.
