Troubleshooting Based on Equipment Condition SiBE27-702
132 Troubleshooting
2. Troubleshooting Based on Equipment Condition
2.1 Overview of General Problems
Overview
Equipment Condition Remedy
1 Equipment does not operate. See page 133
2 Fan operates, but compressor does not. See page 135
3 Cooling/heating operation starts but stops
immediately.
See page 137
4 After unit shuts down, it cannot be
restarted for a while.
See page 139
5 Equipment operates but does not provide
cooling.
See page 141
6 Equipment operates but does not provide
heating.
See page 143
7 Equipment discharges white mist. See page 145
8 Equipment produces loud noise or shakes. See page 146
9 Equipment discharges dust. See page 148
10 Remote controller LCD displays “88.” See page 149
11 Indoor swing flap does not operate. See page 150
12 Equipment emits odor. Room smell and cigarette odors
accumulated inside the indoor unit are
discharged with air. Inside of the indoor
unit must be cleaned.
13 Flap operates when power is turned on. It is normal. The flap initializes for accurate
positioning.
14 Change of operation mode causes flap to
move.
It is normal. There is a control function that
moves the flap when operation mode is
changed.
15 Fan operates in “M” mode during heating
even if remote controller is set to “Low.”
It is normal. It is caused by the activation of
the overload control (airflow shift control).
16 Flap automatically moves during cooling. It is normal. It is caused by the activation of
the dew prevention function or ceiling
soiling prevention function.
17 Indoor unit fan operates in “L” mode for 1
minute in microcomputer-controlled dry
mode even if compressor is not operating.
It is normal. The monitoring function
forcibly operates the fan for one minute.
18 In simultaneous ON/OFF multi-system
setup, indoor unit (sub) does not operate in
sync with the other indoor unit (main).
(Flat, fan, etc.)
It is normal. It is caused by a signal
transmission lag.
19 Indoor unit fan operates after heating
operation stops.
It is normal. The fan operates in the “LL”
mode for 60 to 100 seconds to dissipate
the residual heat in the heater.
20 Drain pump operates when equipment is
not operating.
It is normal. The drain pump continues to
operate for several minutes after
equipment is turned off.
21 Horizontal swing sends air to different
directions in cooling and heating even if it
is set to the same position.
It is normal. The airflow direction in cooling/
dry operation is different from that in
heating/fan operation.
22 Flap remains horizontal even if it is set to
Swing.
It is normal. The flap does not swing in the
thermostat OFF mode.
