Konica Minolta EP2030 [107/151] Copier multi bypass section

When an Indicator Lights Up

EP2030 5-19

6 Fan the paper and reload it.

NOTE

è Make sure that the paper stack rests under the two catches of the

Drawer.

7 Gently slide the Drawer back in.

Copier (Multi Bypass Section)

1 Unload the stack of paper from the

Multi Bypass Tray.

2 Open the Front Door. Turn the Lock

Release Lever clockwise counterto

unlock and swing up the Upper Half

of the copier. Then lock Stopper
