Miscellaneous
7
EP2030 7-11
Conditions for Combined Functions
Functions Conditions
A to F The settings can be made only when the copier is equipped with the
following options.
A Duplex Unit
B Duplexing Document Feeder
C Automatic Document Feeder
D 10-Bin Sorter
EStapleSorter
G The Cover mode cannot be selected when any of the following settings
hasbeenmade for Orig.Ö Copy. If any of them is selected after the Cover
Mode has been selected, it cancels the Cover Mode.
1 Ö 2
Book Ö 1
1 Ö 2[2in1]
Book Ö 2
H You cannotselectBook1if you have previously loadedan original into the
Automatic/ Duplexing Document Feeder. If you load an original into the
Automatic/DuplexingDocumentFeederafteryou haveselected Book Ö 1,
the copier cancels Book Ö 1 and selects 1 Ö 1.
I The Sort-and-Staple mode can be used only when you load two or more
originals into the Automatic/Duplexing Document Feeder
J The Cover mode can be used only when the Automatic/Duplexing
Document Feeder and Multi Bypass Tray are used.
K The Interrupt mode takes precedence. The Interrupt mode cannot be used
if 1 Ö 2, 2 Ö 2, 1 Ö 2[2in1], or Book Ö 2 has been set in the copy-job
program previously called up.
L A zoom ratio or a copy-job program set in the Interrupt mode cannot be
stored in memory.
MBookÖ 1orBookÖ 2 can be combined with the Sort-and-Staple mode,
butnostapling actiontakesplace.(The copierperformsonly bookcopying
and sorting of copies, but not stapling.)
