Konica Minolta EP2030 [56/151] Fixed zoom ratios

Making Copies

3-20 EP2030

Fixed Zoom Ratios

The copier provides most frequently used zoom ratios ready for

immediate use.

1 Press the or Key to select a

fixed zoom ratio of your choice.

NOTE

è The Zoom Ratio Indicator displays the actual value of the selected

ratio.

Using Zoom Up/Down Keys

Pressing the or key changes the zoom ratio shown in 0.001

increments. You can hold down the key to change the ratio quickly.

1 Holddownthe or keyuntilthe

desired zoom ratio is reached

Useful Tip

To save time,firstselect the fixedzoom ratio nearestto thetargetratio

before using theorKey.

Full Size

B4 A3

B4 A4

A3 A4

0.5~2.0
