2
Allgemeine Informationen über das Kopiersystem
2-16 EP2030
Automatische Ausschaltung
Über die automatische Ausschaltung wird der Kopierer nach einer
vorgegebenen Zeit ausgeschaltet, wenn keine neuen Eingaben
vorgenommen wurden. Die Grundstellung ist 60 Minuten.
Tips
Als Zeitraum, nach dessen Ablauf die automatische Ausschaltung
aktiviert wird, können über das Bedienerprogramm 1 bis 98 oder 240
Minuten eingestellt werden (siehe Seite 4-10).
Die automatische Ausschaltung kann auch deaktiviert werden (siehe
Seite 4-5).
HINWEIS
è WendenSiesich an denKundendienst, wenn Sie diese Funktionnicht
aktivieren möchten.
Unterbrechung
Mit dieser Funktion können Sie Mehrfachkopiervorgänge unterbrechen
unddringendereKopiervorgängeeinschieben.Durcheinmaliges Drücken
der Unterbrechen-Taste wird die Unterbrechung aktiviert. Durch
nochmaliges Drücken dieser Taste wird die Unterbrechung deaktiviert,
und die ursprünglichen Einstellungen werden wiederhergestellt.
Tips
Wenn beim aktuellen Kopiervorgang zweiseitiges Kopieren oder die
Deckblattfunktion gewählt wurden, kann die Unterbrechung nicht
aktiviert werden.
Falls im aktuellen Kopiervorgang Sortieren, Sortieren-und-Heften
oder Gruppierenaktiviert wurde, wird automatisch beimAktivierender
Unterbrechung Nicht-Sortieren ausgewählt.
