Konica Minolta EP2030 [40/151] Placing originals

Making Copies

3-4 EP2030

3.2 Placing Originals

Placing on the Original Glass

Different methods are used to place the original depending on its type.

Use the appropriate procedure.

Sheet Originals

(Using plain paper or thick paper)

1 Raise the Original Cover.

2 Place the original face down on the

Original Glass.

3 Align the rear left corner of the

original with the marker on the

Original Width Scale.

4 Gently lower the Original Cover.
