Konica Minolta EP2030 [44/151] Originals not suitable

Making Copies

3-8 EP2030

Originals Not Suitable

 Typing paper, paraffin paper, and other thin paper

 Thick paper

 Originals greater than A3 or smaller than A5L

 OHP transparencies, translucent paper

 Wrinkled, dog-eared, curled, or torn originals

 Clipped or stapled originals

 Carbon-backed originals

NOTE

è For any of these types of originals, place the original manually on the

Original Glass to make a copy, see page 3-7.

Typing paper,

paraffin paper

and other thin

paper

Continuous

forms

Stapled

originals

Thick paper

Wrinkled or

dog-eared

original
