Konica Minolta EP2030 [110/151] Paper feed cabinet pf 112

When an Indicator Lights Up

5-22 EP2030

Paper Feed Cabinet (PF-112)

1 Open the LowerRight Doorandpull

out the sheet of paper.

2 Close the Lower Right Door.

3 Press the Paper Descent Key. This

releases the Drawer, allowing you

to slide it out of the copier.

4 Unload the paper from the Drawer.

Fan the paper and reload it.

5 Slide the Drawer back in and press

the Paper Descent Key.
