Konica Minolta EP2030 [133/151] Specifications
![Konica Minolta EP2030 [133/151] Specifications](/views2/1122108/page133/bg85.png)
Miscellaneous
7
EP2030 7-1
7 Miscellaneous
7.1 Specifications
Copier EP2030
Specification
Type Desk Top Copier
Platen Type Stationary
Photoconductor OPC
Copying System Electrostatic Dry Powdered Image Transfer to Plain Paper
Developing System Micro-Toning System
Fusing System Lamp-Heated Roller
Types of Originals Sheets, Books, and other three-dimensional objects
Maximum Original Size: A3 Lengthwise
Maximum Original Weight: 3kg
Kinds of Paper
Plain paper (60g/m
2
to 90g/m
2
)
Recycled paper
Special paper (Multi Bypass Tray only)
Thick paper (91g/m
2
to 157g/m
2
),
OHP transparencies,
Translucent paper
Copy Paper Size First Drawer
A3L, B4L, A4L, A4C, B5L, B5C, A5L,
FoolscapL (203
×330 mm, 216×330 mm, 210×330 mm)
(WhentheMarketingAreaSwitchisflippedto“Inch”)
11”×17”L, LegalL (8-1/2”×14”), LetterL, 5-1/2”×8-1/2”L
2nd Drawer
A3L, B4L, A4L, A4C, A5L, FoolscapL
254 mm
×203 mmC, 203 mm×330 mmL, 210 mm×280 mmL,
216 mm
×297 mmL, 297 mm×216 mmC, 216 mm×320 mmL,
220 mm
×280 mmL, 297 mm×430 mmL, 210 mm×330 mmL
Multi Bypass Tray
Crosswise: 100 mm to 297 mm
Lengthwise: 140 mm to 432 mm
Paper Feeding System
First Drawer: 250 sheets
2nd Drawer: 250 sheets
Multi Bypass Tray:
50 sheets (80g/m
2
)
20 sheets (recycled paper, thick paper, translucent paper)
5 sheets (OHP transparencies)
Warm-up Time 30 seconds or less at Ambient temperature of 23°C/73°F
(20 seconds or less when the Energy Saver Mode is used)
First Copy A4C = 7.2 seconds or less
(in Full Size Mode using First Copier Drawer)
Copy Speed
(Approx. copies/minute)
Full size (x1.000)
A3L: 13, B4L: 13, A4L: 17, A4C: 23
