Konica Minolta EP2030 [120/151] Removing the i u from the copier

When an Indicator Lights Up

5-32 EP2030

Removing the I. U. from the Copier

1 Open the Front Door. Turn theLock

Release Lever clockwise counter to

unlock and swing up the Upper Half

of the copier. Then lock Stopper

2 Turn the I. U. Lock Release Lever

and, whileholdingitdown,pulltheI.

U. halfway out of the copier.

3 Firmly grasp the I. U. with both

hands and pull it all the way out of

the copier.
