Konica Minolta EP2030 [14/151] Space requirements

Safety Notes

1-2 EP2030

Space Requirements

To ensure easy copier operation, supply replacements, and service

maintenance, adhere to the recommended space requirements detailed

below.

NOTE

è Be sure to allow a clearance of 150 mm or more at the back of the

copier as there is a ventilation duct.

Scale: mm

1,632

1,359

1,055

6501.632230 304

448

1,123

675

1,400

1,043

918
