Allgemeine Informationen über das Kopiersystem
2
EP2030 2-17
Energiesparfunktion
In der EnergiesparfunktionwirdderEnergieverbrauchIhres Kopierers auf
ein Minimum beschränkt. Ist die Energiesparfunktion aktiviert, benötigt
der Kopierer nur ca. 20 Sekunden zum Aufwärmen.
Die Energiesparfunktion wird automatisch nach Ablauf eines
bestimmten Zeitraums ohne Bedienereingaben aktiviert. Die
Grundstellung ist 15 Minuten.
Durch Drücken der Energiespartaste wird die Energiesparfunktion
aktiviert.
Drücken Sie zum Beenden der Energiesparfunktion eine beliebige
Taste im Bedienfeld, z. B. die Start-Taste.
Tip
Als Zeitraum, nach dessen Ablauf die Energiesparfunktion aktiviert
wird, können über das Bedienerprogramm 1 bis 98 oder 240 Minuten
eingestellt werden (siehe Seite 4-9).
HINWEIS
è Der Kopierer wird ausgeschaltet, wenn die Automatische
Ausschaltung bei gleichzeitig aktivierter Energiesparfunktion aktiviert
wird.
