Konica Minolta EP2030 [52/151] Auto paper mode

Making Copies

3-16 EP2030

3.4 Copy Paper Size

Theselected copy papersizeandthe papersourceloadedwiththatpaper

are indicated on the control panel.

Auto Paper Mode

The Auto Paper Mode automatically selects the copy paper according to

the size of the original being used and the zoom ratio selected for use.

1 Press the Paper Select Key to set

the copier into the Auto Paper

mode.

Useful Tip

This mode is efficient when you want to make copies on paper of the

same size as your originals automatically.

FLS.

Inch

Auto


Lighter Darker

0.5~2.0

Auto

Full Size

Full Size Paper

123

456

789

B4 A3

B4 A4

A3 A4

Auto

Auto / Photo

FLS.

Inch

Auto

Paper
