Making Copies
3
EP2030 3-7
Using the Automatic/Duplexing Document Feeder
The Automatic/Duplexing Document Feeder automatically feeds in sheet
originals placed on the Document Feed Tray one by one. After the copy
cycle has been completed, it automatically ejects the original out onto the
Document Exit Tray.
Someoriginals may not be suitable for reliable operation of the Document
Feeder. Here is a guide.
Originals Suitable for the Automatic/Duplexing Document Feeder
Type of Originals:
Sheets (Plain paper)
Normal mode
1-Sided Original (weighing 50g/m
2
to 110g/m
2
)
2-Sided Original (weighing 60g/m
2
to 90g/m
2
)
Mixed Original Detection mode (weighing 60g/m
2
to 90g/m
2
)
Lightweight Original Mode (40g/m
2
to 110g/m
2
)
Original Size:
1-Sided Original,2-Sided Original, Mixed Original Detection Mode
A3L, B4L, A4L, A4C, 210mm×330mm
A5L (Except for Mixed Original Detection Mode)
2-in-1 (Dual Original Scanning) mode : A4C
NOTE
Lightweight Original
BesuretousetheUser’s Choice toturnON theLightweight OriginalMode
when making copies from the lightweight originals.
è For a Lightweight original (40g/m
2
to 50g/m
2
), it is recommended to
place it directly onto the Original Glass or to make copies using the
SADF Mode (Single Automatic Document Feeding Mode),
see page 3-11.
