Konica Minolta EP2030 [85/151] U 51 to 54 special paper setting

Using the User Mode

EP2030 4-11

U-51 to 54 Special Paper Setting

Designates each drawer of the copier for special paper.

For more details on the special paper setting see page 3-18..

U-51 : 1st Drawer

U-52 : 2nd Drawer

U-53 : 3rd Drawer (Setting is possible only when the Paper Feed

Cabinet is mounted.)

U-54 : 4th Drawer (Setting is possible only when the Paper Feed

Cabinet is mounted.)

Setting Description Initial Setting

0 Special paper setting is not made.



1 Special paper setting is made for the drawer.
