Miscellaneous
7
EP2030 7-3
Automatic Document Feeder AF-5
Specification
Document Feeding
System
Standard Mode: 1-sided original, 2-in-1, Single Feeding
Mixed Original Detection Mode: 1-sided Mixed Original
Detection
Lightweight Original Mode
Kinds of Original Plain paper
Original Weight 1-sided Original Mode, 2-in-1 Mode: 50g/m
2
to 110g/m
2
Mixed Original Detection Mode: 60g/m
2
to 90g/m
2
Single Feeding Mode: 35g/m
2
to 157g/m
2
Lightweight Original Mode: 40g/m
2
to 110g/m
2
Original Size 1-sided original Mode:
A3L, B4L, A4L, A4C, A5L, 210 mm
×330 mm
2-in-1 Mode:
A4C
Capacity of Document
Feed Tray
A4 or Smaller: 50 sheets (80g/m
2
)
A3, B4: 30 sheets (80g/m
2
)
Copy Productivity 100%
First Copy with ADF A4C = 11 seconds or less
Power Source DC24V supplied from copier
Power Consumption 48W or less
Dimensions Width: 587 mm Depth: 505 mm Height: 125 mm
Weight 12.0 kg
