Allgemeine Informationen über das Kopiersystem
2-18 EP2030
Programmspeicher
Ein Kopierprogramm, das oft benötigt wird, kann gespeichert und bei
Bedarf aufgerufen werden.
Programmspeichereinstellungen
1 DrückenSiedieTasteEINGABEfür
den Programmspeicher.
Die Programmspeicheranzeige
blinkt.
2 Geben Sie die gewünschten
Kopierfunktionen auf dem
Bedienfeld ein.
3 Drücken Sie die Taste
PROGRAMMSPEICHER.
Die Programmspeicheranzeige
leuchtet, und das Kopierprogramm
wurde im Programmspeicher
gespeichert.
è Um ein Programm aufzurufen,
drücken Sie die Taste
PROGRAMMSPEICHER.
HINWEIS
è Haben Sie ein falsches Programm gespeichert, oder wollen Sie im
vorhandenen Programm etwas ändern, wiederholen Sie bitte die
Schritte 1 bis 3.
Drum
Dehumidify
Input
Job
Memory
Cover
Job
Memory
