Allgemeine Informationen über das Kopiersystem

2-8 EP2030

Pos. Bezeichnung Erklärung

Papiermagazinunterschrank PF-206

1 3. Papiermagazin: Faßt bis zu 500 Blatt Papier (siehe Seite 5-4).

2 4. Papiermagazin: Faßt bis zu 500 Blatt Papier (siehe Seite 5-4).

Duplexeinheit AD-11 / Papiermagazinunterschrank PF-6D

3 Papierführung: Öffnen Sie diese, um einen Papierstau zu beheben

(siehe Seite 5-23).

Papiermagazinunterschrank PF-112

4 3. Papiermagazin: Faßt bis zu 2.500 Blatt Papier (siehe Seite 5-5).

5 Papiersenktaste: DrückenSiediese,bevorSiedasPapiermagazinöffnen

oder schließen (siehe Seite 5-5).
