EP2030 X-3
As an ENERGY STAR
®
Partner, we
have determined that this copier meets
the ENERGY STAR
®
Guidelines for
energy efficiency.
What is an Energy Star Copier?
Energy Star Copiers have a feature that allows them to automatically turn
off or “go to sleep” after a period of inactivity, ensuring night and weekend
shut off. This auto-feature can reduce a copier’s annual electricity costs
by over 60 percent. In addition, high speed copiers will be set to
automatically make double sided copies. An organization’s paper costs
can be reduced and the volume of paper sent into the waste stream will
decline. It takes 10 times more energy to produce a piece of paper than it
does to make a single copy on a copier. Therefore, using less paper also
means decreased national energy consumption.
