When an Indicator Lights Up

5-2 EP2030

3 Load the paper stack into the

Drawer so that its front side faces

down. Make sure that the paper

stackrests underthetwocatchesof

the Drawer.

NOTE

è The paper should be loaded no

higher than the Ä (Max. Level

Indicator) on the Edge Guide.

4 Slide the Edge Guides up against

the paper. Gently slide the Drawer

back in.

NOTE

è When loading Inch Size paper into

the Drawer flip the Marketing Area

Switch, located in the rear left

corneroftheDrawerto“Inch”.
