When an Indicator Lights Up

5-6 EP2030

3 Load another paper stack into the

left half of the Drawer, front side

face down. Press the trailing edge

of the paper stack tightly up against

the left side of the Drawer.

NOTE

è The paper should be loaded no

higher than the (Max. Level

Indicator).

4 Gently slide the Drawer back in and

press the Paper Descent Key.
