Zyxel NXC2500 [100/275] Layer 2 isolation profile commands
![Zyxel NXC2500 [100/275] Layer 2 isolation profile commands](/views2/1169008/page100/bg64.png)
Chapter 10 Wireless LAN Profiles
NXC CLI Reference Guide
100
10.6 Layer-2 Isolation Profile Commands
The following table identifies the values required for many of these commands. Other input
values are discussed with the corresponding commands.
The following table describes the commands available for layer-2 isolation profile
management. You must use the
configure terminal command to enter the configuration
mode before you can use these commands.
Table 40 Input Values for General Layer-2 Isolation Profile Commands
LABEL DESCRIPTION
l2isolation_profile_n
ame
The layer-2 isolation profile name. You may use 1-31 alphanumeric
characters, underscores (
_), or dashes (-), but the first character cannot
be a number. This value is case-sensitive.
mac The Ethernet MAC address of the device that you want to allow to be
accessed by other devices in the SSID to which the layer-2 isolation
profile is applied. Enter 6 hexidecimal pairs separated by colons. You
can use 0-9, a-z and A-Z.
description Sets the description of the profile. You may use up to 60 alphanumeric
characters, underscores (
_), or dashes (-). This value is case-sensitive.
Table 41 Command Summary: Layer-2 Isolation Profile
COMMAND DESCRIPTION
show wlan-l2isolation-profile {all |
l2isolation_profile_name}
Displays the layer-2 isolation profile(s).
all: Displays all profiles.
l2isolation_profile_name: Displays the specified
profile.
wlan-l2isolation-profile rename
l2isolation_profile_name1
l2isolation_profile_name2
Gives an existing layer-2 isolation profile
(l2isolation_profile_name1) a new name
(l2isolation_profile_name2).
[no] wlan-l2isolation-profile
l2isolation_profile_name
Enters configuration mode for the specified layer-2
isolation profile. Use the no parameter to remove the
specified profile.
[no] mac description description Sets a MAC address associated with this profile and the
profile description. Use the no parameter to clear the
settings.
Note: If a device’s MAC addresses is NOT
listed in a layer-2 isolation profile, it is
blocked from communicating with other
devices in an SSID on which layer-2
isolation is enabled.
description description Sets the description for the profile.
exit Exits configuration mode for this profile.
