Chapter 3 Object Reference
NXC CLI Reference Guide
36
3.1.1 Object Reference Command Example
This example shows how to check which configuration is using an address object named
LAN1_SUBNET. For the command output, firewall rule 3 named LAN1-to-NXC is using the
address object.
show reference object-group aaa
radius [group_name]
Displays which configuration settings reference the
specified AAA RADIUS group object.
show reference object [wlan-
radio-profile]
Displays the specified radio profile object.
show reference object [wlan-
monitor-profile]
Displays the specified monitor profile object.
show reference object [wlan-
ssid-profile]
Displays the specified SSID profile object.
show reference object [wlan-
security-profile]
Displays the specified security profile object.
show reference object [wlan-
macfilter-profile]
Displays the specified macfilter profile object.
Table 7 show reference Commands (continued)
COMMAND DESCRIPTION
Router(config)# show reference object address LAN1_SUBNET
LAN1_SUBNET References:
Category
Rule Priority Rule Name
Description
===========================================================================
Firewall
3 N/A
LAN1-to-NXC
Router(config)#
