Chapter 34 File Manager
NXC CLI Reference Guide
208
34.6.4 Command Line FTP Configuration File Download Example
The following example gets a configuration file named today.conf from the NXC and saves it
on the computer as current.conf.
Figure 18 FTP Configuration File Download Example
34.7 Firmware Update Scheduling Commands
The NXC can be scheduled to install the firmware you uploaded at the specified date and time.
The following table lists the commands that you can use for firmware update scheduling.
34.8 NXC File Usage at Startup
The NXC uses the following files at system startup.
C:\>ftp 192.168.1.1
Connected to 192.168.1.1.
220 FTP Server [192.168.1.1]
User (192.168.1.1:(none)): admin
331 Password required for admin.
Password:
230 User admin logged in.
ftp> bin
200 Type set to I
ftp> cd conf
250 CWD command successful
ftp> get today.conf current.conf
200 PORT command successful
150 Opening BINARY mode data connection for conf/today.conf
(20220 bytes)
226 Transfer complete.
ftp: 20220 bytes received in 0.03Seconds 652.26Kbytes/sec.
Table 116 Firmware Update Scheduling Commands Summary
COMMAND DESCRIPTION
firmware-update-schedule activate Turns on the firmware update scheduling feature.
no firmware-update-schedule activate Turns off the firmware update scheduling feature.
firmware-update-schedule time date time Sets the day in year-month-date format and the time of
the day in 24-hour format (for example 23:00 equals
11:00 pm) to install the firmware.
date: yyyy-mm-dd
time: hh:mm
no firmware-update-schedule time Removes the schedule settings.
show firmware-update-schedule status Displays the version of the firmware that you uploaded
to the NXC (via FTP or the Web Configurator) and the
current firmware update scheduling settings.
