Chapter 32 System Remote Management
NXC CLI Reference Guide
198
32.9.2 TR-069 Commands Examples
The following example shows you how to enable TR-069 management on the NXC, set the
management server address and display the TR-069 configurations.
32.10 Language Commands
Use the language commands to display what language the web configurator is using or
change it.
You must use the configure terminal command to enter the configuration
mode before you can use these commands.
[no] tr069-agent username username Enters up to 255 characters to set the user name
used to authenticate the management server
when connecting to the NXC. The no command
removes the password.
[no] tr069-agent vantage certificate certificate Sets the management server’s certificate. This
applies when you enable HTTPS authentication.
show tr069-agent configuration Displays TR-069 Settings.
Table 108 Command Summary: TR-069 (continued)
COMMAND DESCRIPTION
Router# configure terminal
Router(config)# tr069-agent activate
Router(config)# tr069-agent manager https://10.1.2.3
Router(config)# show tr069-agent configuration
Activate: YES
ACS URL: https://10.1.2.3
Connection Request URL:
ACS Username:
ACS Password:
Username:
Password:
Provisioning Code:
Server Type: TR069 ACS
Keepalive: ENABLE
Keepalive Interval: 20
Periodic Inform: DISABLE
Periodic Inform Interval: 3600
Custom IP: NO
HTTPS Authentication: NO
Vantage Certificate:
Router(config)#
Table 109 Command Summary: Language
COMMAND DESCRIPTION
language <English |
Simplified_Chinese |
Traditional_Chinese>
Specifies the language used in the web configurator
screens.
show language {setting | all} setting displays the current display language in the web
configurator screens.
all displays the available languages.
