Chapter 28 Authentication Server
NXC CLI Reference Guide
172
28.2.1 Authentication Server Command Examples
The following example shows you how to enable the authentication server feature on the NXC
and sets a trusted RADIUS client profile. This example also shows you the authentication
server and client profile settings.
[no] description
description
Sets the description for the profile. The no command clears this
setting.
description: You can use alphanumeric and
()+/
:=?!*#@$_%- characters, and it can be up to 60 characters
long.
show auth-server status Displays the NXC’s authentication server settings.
show auth-server trusted-
client
Displays all RADIUS client profile settings.
show auth-server trusted-
client profile_name
Displays the specified RADIUS client profile settings.
Table 91 Command Summary: Authentication Server (continued)
COMMAND DESCRIPTION
Router# configure terminal
Router(config)# auth-server activate
Router(config)# auth-server trusted-client AP-1
Router(config-trusted-client-AP-1)# activate
Router(config-trusted-client-AP-1)# ip address 10.10.1.2 255.255.255.0
Router(config-trusted-client-AP-1)# secret 12345678
Router(config-trusted-client-AP-1)# exit
Router(config)# show auth-server status
activation: yes
authentication method: default
certificate: default
Router(config)# show auth-server trusted-client AP-1
Client: AP-1
Activation: yes
Description:
IP: 10.10.1.2
Netmask: 255.255.255.0
Secret: VQEq907jWB8=
Router(config)#
