Chapter 41 Watchdog Timer
NXC CLI Reference Guide
248
The following example lists the processes that the application watchdog is monitoring.
Router# configure terminal
Router(config)# show app-watch-dog monitor-list
#app_name min_process_count max_process_count(-1 unlimited) recover_enable
recover_reboot recover_always recover_max_try_count ecover_max_fail_count
uamd 1 -1 1
2 1 1 3
firewalld 1 -1 0
1 1 1 3
policyd 1 -1 1
1 1 1 3
classify 1 -1 0
1 1 1 3
resd 1 -1 0
1 1 1 3
zyshd_wd 1 -1 0
1 1 1 3
zyshd 1 -1 0
0 1 1 3
httpd 1 -1 1
httpd 1 -1 1
dhcpd 1 -1 1
1 1 1 3
zylogd 1 -1 0
1 1 1 3
syslog-ng 1 -1 0
1 1 1 3
zylogger 1 -1 0
1 1 1 3
ddns_had 1 -1 0
1 1 1 3
zebra 1 -1 0
1 1 1 3
link_updown 1 -1 0
1 1 1 3
fauthd 1 -1 0
1 1 1 3
signal_wrapper 1 -1 0
1 1 1 3
capwap_srv 1 1 0
1 1 1 3
ipmonitord 1 -1 0
1 1 1 3
Router(config)#
